there are various pipe fittings manufacturing processes that are used to manufacture elbow, tee, reducers, and other pipe fittings.

fittings are manufactured from a seamless pipe and from welded pipe with filler material (erw & efw pipes cannot be used to manufacture fittings). large diameter fittings are manufactured from plates.

to manufacture wrought fitting various methods are used; these are the different types of hot and cold forming processes.

these methods are

• hot forming or extrusion method
• hydraulic bulge method–cold forming
• uo or single weld seam method
• monaka or double weld seam method
• deep drawing method for caps
• flare method for stub ends

elbows manufacturing process:

mandrel method (hot forming)
one of the most common pipe fittings manufacturing process for manufacturing elbows from the pipe is the mandrel method, a kind of hot forming method.
in this method, the pipe is cut into pieces and pushed with the help of a hydraulic ram. an induction heating coil heats the pipe, and it is pushed over a die called a “mandrel,” which allows the pipe to expand and bend simultaneously.
this method can be used to manufacture a wide range of the diameter of elbows.

                                                      elbows mandrel method

extrusion method

in the cold extrusion method, a pipe with the same diameter as a finished product is pushed through a die and formed into its desired shape. usually applied to stainless steel small to medium sizes elbows.

uo method

uo method is used to manufacture the medium size of elbow, tee, and reducers. the plate is cut out into a specially designed shape, it is formed first into a u-shape using a die and then into an o-shape or tubular form using another die; that is why this method is known as the uo method.
once the fittings are tumbler shaped, they are welded from inside and outside of the closing seam. a cut plate is 1st from in u shape and then in o shape.

                               uo method

hot forming method

in a hot forming die bending method, a pipe is heated to forming temperature & formed in the die with the specific shape, this process may be repeated as needed to obtain the required shape, size, and wall thickness. usually applied to thick-wall items that cannot be bent on a mandrel die. you can learn about elbows in this article.

                                            hot forming method for elbow manufacturing

                             hydraulic bulge method for tee manufacturing

in the hot extrusion method, normally bigger diameter pipe is used than the finished product size, and the branch outlet is extruded from the pipe with the help of the extrusion tool. other dimensions of the body and branch can also be adjusted by pressing the die if required.

hydraulic bulge method for tee manufacturing

hot extrusion method
tee with large diameters, heavy wall thickness, and /or special material with challenging workability that cannot be manufactured using the hydraulic bulge method is manufactured using the hot extrusion method.
in the hot extrusion method, normally bigger diameter pipe is used than the finished product size, and the branch outlet is extruded from the pipe with the help of the extrusion tool. other dimensions of the body and branch can also be adjusted by pressing the die if required.

                                                 outer die method

caps are manufactured by the deep drawing method. in this method, plate is cut out in a circle and formed by a deep-drawing die.

                                   deep drawing method

stub ends or lap joints flange are manufactured by the flaring method. the pipe end is a flare or spared out from a flange face. stub ends are also manufactured by forging, in which forge block is machined to the final dimension.
