PORTÉE |
Pieux de tuyau d'acier pour le membre porteur permanent et structurel ou comme coquille pour former les piles concrètes moulées sur place. |
|
Spécification |
ASTM A252, GRADES 2 ET 3/MODIFIÉ À 50 KSI MIN. RENDEMENT |
|
Processus de fabrication |
SOUDURE ÉLECTRIQUE DE RÉSISTANCE DE DROITE-COUTURE (ERW) |
|
TAILLE (OD) |
8.625, 10.750 et 12.750 |
|
JAUGE/ÉPAISSEUR DE PAROI |
0,250, 0,313, 0,375 et 0,500 (nominal) |
|
PROPRIÉTÉS DE RÉSISTANCE/ÉLONGATION |
RENDEMENT: 50 KSI MIN., 60 KSI MIN., 75 KSI MIN., 80 KSI MIN. Viser. |
|
TOLÉRANCE DE DROITE |
1/8 ”X LONGUEUR (EN PIEDS), DIVISÉ PAR CINQ |
Astm A53 est publié par l'American Society for Testing and Materials (Astm), qui est une spécification standard pour les tuyaux en acier sans soudure et soudés conçus pour une variété d'applications. Ce passage est un aperçu des tuyaux en acier sans soudure Astm A53, lisez la suite pour en savoir plus.
Grades de tuyau d'acier A53:
Les tuyaux d'acier d'Astm A53 viennent dans différentes catégories, avec les plus communs étant:
-Grade A: Ce grade est destiné à un usage général et n'est pas destiné à des applications sous pression ou structurelles. Il est souvent utilisé pour les systèmes de plomberie et de distribution d'air à basse pression.
Grade B: Grade B est la catégorie la plus couramment utilisée et convient à une gamme d'applications, y compris les systèmes à haute pression, l'eau et autres fluides, ainsi que les applications structurelles. Il est plus robuste que le grade A.
Variations permises pour le tuyau d'acier A53:
-Épaisseur de paroi: L'épaisseur minimale de paroi en tout point ne doit pas dépasser 12,5% sous l'épaisseur nominale de paroi spécifiée.
Les poids par pied sont plus ou moins 10%
-Diamètre extérieur: Le diamètre extérieur en tout point ne variera pas de la norme spécifiée Plus que:
|
NPS |
Sur |
Sous |
|
1-1/2 et plus petit |
+ 1/64» |
1/64» |
|
2 et plus grand |
+ 1% |
-1% |
Applications de tuyau d'acier a53:
-Transport de fluide: ces tuyaux sont couramment utilisés pour le transport d'eau, de pétrole, de gaz et d'autres fluides dans les systèmes à haute et à basse pression.
-Utilisation structurelle: les tuyaux en acier astm a53 de grade b sont utilisés dans des applications structurelles, telles que la construction de bâtiments, de ponts et d'autres infrastructures.
-Applications mécaniques et de pression: les tuyaux de la catégorie b conviennent aux applications où les propriétés mécaniques et la résistance à la pression sont essentielles.
-Protection incendie: les tuyaux astm a53 sont souvent utilisés pour les systèmes de gicleurs d'incendie.
-Cvc (chauffage, ventilation et climatisation): ils sont utilisés dans les systèmes de cvc pour transporter l'air et d'autres gaz.
|
NOMINAL PIPE SIZE |
OD (mm) |
NOMINAL WALL THICKNESS |
|||||||||||||
|
DN |
NB(inch) |
ASME |
SCH10 |
SCH20 |
SCH30 |
STD |
SCH40 |
SCH60 |
XS |
SCH80 |
SCH100 |
SCH120 |
SCH140 |
SCH160 |
XXS |
|
15 |
1/2" |
21.3 |
2.11 |
|
2.41 |
2.77 |
2.77 |
|
3.73 |
3.73 |
|
|
|
4.78 |
7.47 |
|
20 |
3/4" |
26.7 |
2.11 |
|
2.41 |
2.87 |
2.87 |
|
3.91 |
3.91 |
|
|
|
5.56 |
7.82 |
|
25 |
1" |
33.4 |
2.77 |
|
2.9 |
3.38 |
3.38 |
|
4.55 |
4.55 |
|
|
|
6.35 |
9.09 |
|
32 |
1.1/4" |
42.2 |
2.77 |
|
2.97 |
3.56 |
3.56 |
|
4.85 |
4.85 |
|
|
|
6.35 |
9.7 |
|
40 |
1.1/2" |
48.3 |
2.77 |
|
3.18 |
3.68 |
3.68 |
|
5.08 |
5.08 |
|
|
|
7.14 |
10.15 |
|
50 |
2" |
60.3 |
2.77 |
|
3.18 |
3.91 |
3.91 |
|
5.54 |
5.54 |
|
|
|
8.74 |
11.07 |
|
65 |
2.1/2" |
73 |
3.05 |
|
4.78 |
5.16 |
5.16 |
|
7.01 |
7.01 |
|
|
|
9.53 |
14.02 |
|
80 |
3" |
88.9 |
3.05 |
|
4.78 |
5.49 |
5.49 |
|
7.62 |
7.62 |
|
|
|
11.13 |
15.25 |
|
90 |
3.1/2" |
101.6 |
3.05 |
|
4.78 |
5.74 |
5.74 |
|
8.08 |
8.08 |
|
|
|
|
|
|
100 |
4" |
114.3 |
3.05 |
|
4.78 |
6.02 |
6.02 |
|
8.56 |
8.56 |
|
11.13 |
|
13.49 |
17.12 |
|
125 |
5" |
141.3 |
3.4 |
|
|
6.55 |
6.55 |
|
9.53 |
9.53 |
|
12.7 |
|
15.88 |
19.05 |
|
150 |
6" |
168.3 |
3.4 |
|
|
7.11 |
7.11 |
|
10.97 |
10.97 |
|
14.27 |
|
18.26 |
21.95 |
|
200 |
8" |
219.1 |
3.76 |
6.35 |
7.04 |
8.18 |
8.18 |
10.31 |
12.7 |
12.7 |
15.09 |
18.26 |
20.62 |
23.01 |
22.23 |
|
250 |
10" |
273 |
4.19 |
6.35 |
7.8 |
9.27 |
9.27 |
12.7 |
12.7 |
15.09 |
18.26 |
21.44 |
25.4 |
28.58 |
25.4 |
|
300 |
12" |
323.8 |
4.57 |
6.35 |
8.38 |
9.53 |
10.31 |
14.27 |
12.7 |
17.48 |
21.44 |
25.4 |
28.58 |
33.32 |
25.4 |
|
350 |
14" |
355.6 |
6.35 |
7.92 |
9.53 |
9.53 |
11.13 |
15.09 |
12.7 |
19.05 |
23.83 |
27.79 |
31.75 |
35.71 |
|
|
400 |
16" |
406.4 |
6.35 |
7.92 |
9.53 |
9.53 |
12.7 |
16.66 |
12.7 |
21.44 |
26.19 |
30.96 |
36.53 |
40.19 |
|
|
450 |
18" |
457.2 |
6.35 |
7.92 |
11.13 |
9.53 |
14.27 |
19.05 |
12.7 |
23.83 |
39.36 |
34.93 |
39.67 |
45.24 |
|
|
500 |
20" |
508 |
6.35 |
9.53 |
12.7 |
9.53 |
15.09 |
20.62 |
12.7 |
26.19 |
32.54 |
38.1 |
44.45 |
50.01 |
|
|
550 |
22" |
558.8 |
6.35 |
9.53 |
12.7 |
9.53 |
|
22.23 |
12.7 |
28.58 |
34.93 |
41.28 |
47.63 |
53.98 |
|
|
600 |
24" |
609.6 |
6.35 |
9.53 |
14.27 |
9.53 |
17.48 |
24.61 |
12.7 |
30.96 |
38.89 |
46.02 |
52.37 |
59.54 |
|
|
650 |
26" |
660.4 |
7.92 |
12.7 |
|
9.53 |
|
|
12.7 |
|
|
|
|
|
|
|
700 |
28" |
711.2 |
7.92 |
12.7 |
15.88 |
9.53 |
|
|
12.7 |
|
|
|
|
|
|
|
750 |
30" |
762 |
7.92 |
12.7 |
15.88 |
9.53 |
|
|
12.7 |
|
|
|
|
|
|
|
800 |
32" |
812.8 |
7.92 |
12.7 |
15.88 |
9.53 |
17.48 |
|
12.7 |
|
|
|
|
|
|
|
850 |
34" |
863.6 |
7.92 |
12.7 |
15.88 |
9.53 |
17.48 |
|
12.7 |
|
|
|
|
|
|
|
900 |
36" |
914.4 |
7.92 |
12.7 |
15.88 |
9.53 |
19.05 |
|
12.7 |
|
|
|
|
|
|
Tolerances Of Carbon Seamless Steel Pipe
|
Pipe types |
Pipe sizes(mm) |
Tolerances |
|
Hot rolled |
OD<50 |
±0.50mm |
|
OD≥50 |
±1% |
|
|
WT<4 |
±12.5% |
|
|
WT 4～20 |
+15%, -12.5% |
|
|
WT>20 |
±12.5% |
|
|
Cold drawn |
OD 6～10 |
±0.20mm |
|
OD 10～30 |
±0.40mm |
|
|
OD 30～50 |
±0.45 |
|
|
OD>50 |
±1% |
|
|
WT≤1 |
±0.15mm |
|
|
WT 1～3 |
+15%, -10% |
|
|
WT >3 |
+12.5%, -10% |
|
ASTM A53 Gr.B |
Black and hot-dipped zinc-coated steel pipes welded and seamless |
|
ASTM A106 Gr.B |
Seamless carbon steel for high temperature service |
|
ASTM SA179 |
Seamless cold-drawn low-carbon steel heat exchanger and condenser tubes |
|
ASTM SA192 |
Seamless carbon steel boiler tubes for high pressure |
|
ASTM SA210 |
Seamless Medium-carbon boiler and superheater tubes |
|
ASTM A213 |
Seamless alloy-steel boiler, superheater, and heat-exchanger tubes |
|
ASTM A333 GR.6 |
seamless and welded carbon and alloy steel pipe intended for use at low temperatures. |
|
ASTM A335 P9,P11,T22,T91 |
Seamless ferritic alloy-steel pipe for high-temperature service |
|
ASTM A336 |
Alloy steel forgings for pressure and high-temperature parts |
|
ASTM SA519 4140/4130 |
Seamless carbon for mechanical tubing |
|
API Spec 5CT J55/K55/N80/L80/P110/K55 |
Seamless steel pipe for casing |
|
API Spec 5L PSL1/PSL2 Gr.b, X42/46/52/56/65/70 |
Seamless steel pipe for line pipe |
|
DIN 17175 |
Seamless steel tube for elevated temperture |
|
DN2391 |
Cold drawn seamless prevision pipe |
|
DIN 1629 |
Seamless circular unalloyed steel tubes subject to special requirements |
|
standard |
Grade |
Chemical Components (%) |
Mechanical Properties |
|||||
|
C |
Si |
Mn |
P |
S |
Tensile STrength(Mpa) |
Yield STrength(Mpa) |
||
|
ASTM A53 |
A |
≤0.25 |
- |
≤0.95 |
≤0.05 |
≤0.06 |
≥330 |
≥205 |
|
B |
≤0.30 |
- |
≤1.2 |
≤0.05 |
≤0.06 |
≥415 |
≥240 |
|
|
ASTM A106 |
A |
≤0.30 |
≥0.10 |
0.29-1.06 |
≤0.035 |
≤0.035 |
≥415 |
≥240 |
|
B |
≤0.35 |
≥0.10 |
0.29-1.06 |
≤0.035 |
≤0.035 |
≥485 |
≥275 |
|
|
ASTM A179 |
A179 |
0.06-0.18 |
- |
0.27-0.63 |
≤0.035 |
≤0.035 |
≥325 |
≥180 |
|
ASTM A192 |
A192 |
0.06-0.18 |
≤0.25 |
0.27-0.63 |
≤0.035 |
≤0.035 |
≥325 |
≥180 |
|
API 5L PSL1 |
A |
0.22 |
- |
0.9 |
0.03 |
0.03 |
≥331 |
≥207 |
|
B |
0.28 |
- |
1.2 |
0.03 |
0.03 |
≥414 |
≥241 |
|
|
X42 |
0.28 |
- |
1.3 |
0.03 |
0.03 |
≥414 |
≥290 |
|
|
X46 |
0.28 |
- |
1.4 |
0.03 |
0.03 |
≥434 |
≥317 |
|
|
X52 |
0.28 |
- |
1.4 |
0.03 |
0.03 |
≥455 |
≥359 |
|
|
X56 |
0.28 |
- |
1.4 |
0.03 |
0.03 |
≥490 |
≥386 |
|
|
X60 |
0.28 |
- |
1.4 |
0.03 |
0.03 |
≥517 |
≥448 |
|
|
X65 |
0.28 |
- |
1.4 |
0.03 |
0.03 |
≥531 |
≥448 |
|
|
X70 |
0.28 |
- |
1.4 |
0.03 |
0.03 |
≥565 |
≥483 |
|
|
API 5L PSL2 |
B |
0.24 |
- |
1.2 |
0.025 |
0.015 |
≥414 |
≥241 |
|
X42 |
0.24 |
- |
1.3 |
0.025 |
0.015 |
≥414 |
≥290 |
|
|
X46 |
0.24 |
- |
1.4 |
0.025 |
0.015 |
≥434 |
≥317 |
|
|
X52 |
0.24 |
- |
1.4 |
0.025 |
0.015 |
≥455 |
≥359 |
|
|
X56 |
0.24 |
- |
1.4 |
0.025 |
0.015 |
≥490 |
≥386 |
|
|
X60 |
0.24 |
- |
1.4 |
0.025 |
0.015 |
≥517 |
≥414 |
|
|
X65 |
0.24 |
- |
1.4 |
0.025 |
0.015 |
≥531 |
≥448 |
|
|
X70 |
0.24 |
- |
1.4 |
0.025 |
0.015 |
≥565 |
≥483 |
|
|
X80 |
0.24 |
- |
1.4 |
0.025 |
0.015 |
≥621 |
≥552 |
|
|
Pipe types |
Pipe sizes(mm) |
Tolerances |
|
Hot rolled |
OD<50 |
±0.50mm |
|
OD≥50 |
±1% |
|
|
WT<4 |
±12.5% |
|
|
WT 4～20 |
+15%, -12.5% |
|
|
WT>20 |
±12.5% |
|
|
Cold drawn |
OD 6～10 |
±0.20mm |
|
OD 10～30 |
±0.40mm |
|
|
OD 30～50 |
±0.45 |
|
|
OD>50 |
±1% |
|
|
WT≤1 |
±0.15mm |
|
|
WT 1～3 |
+15%, -10% |
|
|
WT >3 |
+12.5%, -10% |
|
Types |
Application |
|
Structure Purposes |
General structure and mechanical |
|
Liquid Services |
Petroleum, gas and other fluids conveying |
|
Low and Medium Pressure Boiler Tube |
Steam and boiler manufacturing |
|
Hydraulic Pillar Service |
Hydraulic support |
|
Auto Semi-shaft Casing |
Auto sem-shaft casing |
|
Line Pipe |
Oil and gas conveying |
|
Tubing and Casing |
Oil and gas conveying |
|
Drill Pipes |
Well drilling |
|
Geological Drilling Pipe |
Geological drilling |
|
Furnace tubes, heat exchangers tubes |
Furnace tubes, heat exchangers |
|
Chilled water pipe |
Steam/condensate pipe |
Heat exchanger pipe |
Marine/offshore pipe |
Dredging pipe |
Industrial pipe |
|
Oil and gas pipe |
Fire fighting pipe |
Construction/structure pipe |
Irrigation pipe |
Drain/sewage pipe |
Boiler tube |
Propriétés chimiques %
|
/ |
Grade |
C,
Max
|
Mn,
Max
|
P,
Max
|
S,
Max
|
Cu *,
Max
|
Ni *,
Max
|
Cr *,
Max
|
Mo *,
Max
|
V *,
Max
|
|
Type S (sans soudure) |
A | 0.25 | 0.95 |
0.05 |
0.05 |
0.4 |
0.4 |
0.4 |
0.15 | 0.08 |
| B | 0.3 | 1.2 |
0.05 |
0.05 |
0.4 |
0.4 |
0.4 |
0.15 |
0.08 |
|
|
Type E (résistance électrique soudée) |
A | 0.25 |
0.95 |
0.05 |
0.05 |
0.4 |
0.4 |
0.4 |
0.15 |
0.08 |
| B | 0.3 | 1.2 |
0.05 |
0.05 |
0.4 |
0.4 |
0.4 |
0.15 |
0.08 |
|
|
Type F (Soudé au four) |
A | 0.3 | 1.2 |
0.05 |
0.05 |
0.4 |
0.4 |
0.4 |
0.15 |
0.08 |
* La composition totale de ces cinq éléments ne doit pas dépasser 1,00%
Propriétés mécaniques
|
|
Grade A |
Grade B |
|
Résistance à la traction, min., psi, (MPa) |
48 000 (330) |
60 000 (415) |
|
Force d'élasticité, min., psi, (MPa) |
30 000 (205) |
35 000 (240) |
(Remarque: Il s'agit d'informations résumées de la spécification ASME A53. Veuillez se référer à la norme ou à la spécification spécifique ou contactez-nous pour plus de détails.
|
NOMINAL PIPE SIZE |
OD (mm) |
NOMINAL WALL THICKNESS |
|||||||||||||
|
DN |
NB(inch) |
ASME |
SCH10 |
SCH20 |
SCH30 |
STD |
SCH40 |
SCH60 |
XS |
SCH80 |
SCH100 |
SCH120 |
SCH140 |
SCH160 |
XXS |
|
15 |
1/2" |
21.3 |
2.11 |
|
2.41 |
2.77 |
2.77 |
|
3.73 |
3.73 |
|
|
|
4.78 |
7.47 |
|
20 |
3/4" |
26.7 |
2.11 |
|
2.41 |
2.87 |
2.87 |
|
3.91 |
3.91 |
|
|
|
5.56 |
7.82 |
|
25 |
1" |
33.4 |
2.77 |
|
2.9 |
3.38 |
3.38 |
|
4.55 |
4.55 |
|
|
|
6.35 |
9.09 |
|
32 |
1.1/4" |
42.2 |
2.77 |
|
2.97 |
3.56 |
3.56 |
|
4.85 |
4.85 |
|
|
|
6.35 |
9.7 |
|
40 |
1.1/2" |
48.3 |
2.77 |
|
3.18 |
3.68 |
3.68 |
|
5.08 |
5.08 |
|
|
|
7.14 |
10.15 |
|
50 |
2" |
60.3 |
2.77 |
|
3.18 |
3.91 |
3.91 |
|
5.54 |
5.54 |
|
|
|
8.74 |
11.07 |
|
65 |
2.1/2" |
73 |
3.05 |
|
4.78 |
5.16 |
5.16 |
|
7.01 |
7.01 |
|
|
|
9.53 |
14.02 |
|
80 |
3" |
88.9 |
3.05 |
|
4.78 |
5.49 |
5.49 |
|
7.62 |
7.62 |
|
|
|
11.13 |
15.25 |
|
90 |
3.1/2" |
101.6 |
3.05 |
|
4.78 |
5.74 |
5.74 |
|
8.08 |
8.08 |
|
|
|
|
|
|
100 |
4" |
114.3 |
3.05 |
|
4.78 |
6.02 |
6.02 |
|
8.56 |
8.56 |
|
11.13 |
|
13.49 |
17.12 |
|
125 |
5" |
141.3 |
3.4 |
|
|
6.55 |
6.55 |
|
9.53 |
9.53 |
|
12.7 |
|
15.88 |
19.05 |
|
150 |
6" |
168.3 |
3.4 |
|
|
7.11 |
7.11 |
|
10.97 |
10.97 |
|
14.27 |
|
18.26 |
21.95 |
|
200 |
8" |
219.1 |
3.76 |
6.35 |
7.04 |
8.18 |
8.18 |
10.31 |
12.7 |
12.7 |
15.09 |
18.26 |
20.62 |
23.01 |
22.23 |
|
250 |
10" |
273 |
4.19 |
6.35 |
7.8 |
9.27 |
9.27 |
12.7 |
12.7 |
15.09 |
18.26 |
21.44 |
25.4 |
28.58 |
25.4 |
|
300 |
12" |
323.8 |
4.57 |
6.35 |
8.38 |
9.53 |
10.31 |
14.27 |
12.7 |
17.48 |
21.44 |
25.4 |
28.58 |
33.32 |
25.4 |
|
350 |
14" |
355.6 |
6.35 |
7.92 |
9.53 |
9.53 |
11.13 |
15.09 |
12.7 |
19.05 |
23.83 |
27.79 |
31.75 |
35.71 |
|
|
400 |
16" |
406.4 |
6.35 |
7.92 |
9.53 |
9.53 |
12.7 |
16.66 |
12.7 |
21.44 |
26.19 |
30.96 |
36.53 |
40.19 |
|
|
450 |
18" |
457.2 |
6.35 |
7.92 |
11.13 |
9.53 |
14.27 |
19.05 |
12.7 |
23.83 |
39.36 |
34.93 |
39.67 |
45.24 |
|
|
500 |
20" |
508 |
6.35 |
9.53 |
12.7 |
9.53 |
15.09 |
20.62 |
12.7 |
26.19 |
32.54 |
38.1 |
44.45 |
50.01 |
|
|
550 |
22" |
558.8 |
6.35 |
9.53 |
12.7 |
9.53 |
|
22.23 |
12.7 |
28.58 |
34.93 |
41.28 |
47.63 |
53.98 |
|
|
600 |
24" |
609.6 |
6.35 |
9.53 |
14.27 |
9.53 |
17.48 |
24.61 |
12.7 |
30.96 |
38.89 |
46.02 |
52.37 |
59.54 |
|
|
650 |
26" |
660.4 |
7.92 |
12.7 |
|
9.53 |
|
|
12.7 |
|
|
|
|
|
|
|
700 |
28" |
711.2 |
7.92 |
12.7 |
15.88 |
9.53 |
|
|
12.7 |
|
|
|
|
|
|
|
750 |
30" |
762 |
7.92 |
12.7 |
15.88 |
9.53 |
|
|
12.7 |
|
|
|
|
|
|
|
800 |
32" |
812.8 |
7.92 |
12.7 |
15.88 |
9.53 |
17.48 |
|
12.7 |
|
|
|
|
|
|
|
850 |
34" |
863.6 |
7.92 |
12.7 |
15.88 |
9.53 |
17.48 |
|
12.7 |
|
|
|
|
|
|
|
900 |
36" |
914.4 |
7.92 |
12.7 |
15.88 |
9.53 |
19.05 |
|
12.7 |
|
|
|
|
|
|
Tolerances Of Carbon Seamless Steel Pipe
|
Pipe types |
Pipe sizes(mm) |
Tolerances |
|
Hot rolled |
OD<50 |
±0.50mm |
|
OD≥50 |
±1% |
|
|
WT<4 |
±12.5% |
|
|
WT 4～20 |
+15%, -12.5% |
|
|
WT>20 |
±12.5% |
|
|
Cold drawn |
OD 6～10 |
±0.20mm |
|
OD 10～30 |
±0.40mm |
|
|
OD 30～50 |
±0.45 |
|
|
OD>50 |
±1% |
|
|
WT≤1 |
±0.15mm |
|
|
WT 1～3 |
+15%, -10% |
|
|
WT >3 |
+12.5%, -10% |
|
ASTM A53 Gr.B |
Black and hot-dipped zinc-coated steel pipes welded and seamless |
|
ASTM A106 Gr.B |
Seamless carbon steel for high temperature service |
|
ASTM SA179 |
Seamless cold-drawn low-carbon steel heat exchanger and condenser tubes |
|
ASTM SA192 |
Seamless carbon steel boiler tubes for high pressure |
|
ASTM SA210 |
Seamless Medium-carbon boiler and superheater tubes |
|
ASTM A213 |
Seamless alloy-steel boiler, superheater, and heat-exchanger tubes |
|
ASTM A333 GR.6 |
seamless and welded carbon and alloy steel pipe intended for use at low temperatures. |
|
ASTM A335 P9,P11,T22,T91 |
Seamless ferritic alloy-steel pipe for high-temperature service |
|
ASTM A336 |
Alloy steel forgings for pressure and high-temperature parts |
|
ASTM SA519 4140/4130 |
Seamless carbon for mechanical tubing |
|
API Spec 5CT J55/K55/N80/L80/P110/K55 |
Seamless steel pipe for casing |
|
API Spec 5L PSL1/PSL2 Gr.b, X42/46/52/56/65/70 |
Seamless steel pipe for line pipe |
|
DIN 17175 |
Seamless steel tube for elevated temperture |
|
DN2391 |
Cold drawn seamless prevision pipe |
|
DIN 1629 |
Seamless circular unalloyed steel tubes subject to special requirements |
|
standard |
Grade |
Chemical Components (%) |
Mechanical Properties |
|||||
|
C |
Si |
Mn |
P |
S |
Tensile STrength(Mpa) |
Yield STrength(Mpa) |
||
|
ASTM A53 |
A |
≤0.25 |
- |
≤0.95 |
≤0.05 |
≤0.06 |
≥330 |
≥205 |
|
B |
≤0.30 |
- |
≤1.2 |
≤0.05 |
≤0.06 |
≥415 |
≥240 |
|
|
ASTM A106 |
A |
≤0.30 |
≥0.10 |
0.29-1.06 |
≤0.035 |
≤0.035 |
≥415 |
≥240 |
|
B |
≤0.35 |
≥0.10 |
0.29-1.06 |
≤0.035 |
≤0.035 |
≥485 |
≥275 |
|
|
ASTM A179 |
A179 |
0.06-0.18 |
- |
0.27-0.63 |
≤0.035 |
≤0.035 |
≥325 |
≥180 |
|
ASTM A192 |
A192 |
0.06-0.18 |
≤0.25 |
0.27-0.63 |
≤0.035 |
≤0.035 |
≥325 |
≥180 |
|
API 5L PSL1 |
A |
0.22 |
- |
0.9 |
0.03 |
0.03 |
≥331 |
≥207 |
|
B |
0.28 |
- |
1.2 |
0.03 |
0.03 |
≥414 |
≥241 |
|
|
X42 |
0.28 |
- |
1.3 |
0.03 |
0.03 |
≥414 |
≥290 |
|
|
X46 |
0.28 |
- |
1.4 |
0.03 |
0.03 |
≥434 |
≥317 |
|
|
X52 |
0.28 |
- |
1.4 |
0.03 |
0.03 |
≥455 |
≥359 |
|
|
X56 |
0.28 |
- |
1.4 |
0.03 |
0.03 |
≥490 |
≥386 |
|
|
X60 |
0.28 |
- |
1.4 |
0.03 |
0.03 |
≥517 |
≥448 |
|
|
X65 |
0.28 |
- |
1.4 |
0.03 |
0.03 |
≥531 |
≥448 |
|
|
X70 |
0.28 |
- |
1.4 |
0.03 |
0.03 |
≥565 |
≥483 |
|
|
API 5L PSL2 |
B |
0.24 |
- |
1.2 |
0.025 |
0.015 |
≥414 |
≥241 |
|
X42 |
0.24 |
- |
1.3 |
0.025 |
0.015 |
≥414 |
≥290 |
|
|
X46 |
0.24 |
- |
1.4 |
0.025 |
0.015 |
≥434 |
≥317 |
|
|
X52 |
0.24 |
- |
1.4 |
0.025 |
0.015 |
≥455 |
≥359 |
|
|
X56 |
0.24 |
- |
1.4 |
0.025 |
0.015 |
≥490 |
≥386 |
|
|
X60 |
0.24 |
- |
1.4 |
0.025 |
0.015 |
≥517 |
≥414 |
|
|
X65 |
0.24 |
- |
1.4 |
0.025 |
0.015 |
≥531 |
≥448 |
|
|
X70 |
0.24 |
- |
1.4 |
0.025 |
0.015 |
≥565 |
≥483 |
|
|
X80 |
0.24 |
- |
1.4 |
0.025 |
0.015 |
≥621 |
≥552 |
|
|
Pipe types |
Pipe sizes(mm) |
Tolerances |
|
Hot rolled |
OD<50 |
±0.50mm |
|
OD≥50 |
±1% |
|
|
WT<4 |
±12.5% |
|
|
WT 4～20 |
+15%, -12.5% |
|
|
WT>20 |
±12.5% |
|
|
Cold drawn |
OD 6～10 |
±0.20mm |
|
OD 10～30 |
±0.40mm |
|
|
OD 30～50 |
±0.45 |
|
|
OD>50 |
±1% |
|
|
WT≤1 |
±0.15mm |
|
|
WT 1～3 |
+15%, -10% |
|
|
WT >3 |
+12.5%, -10% |
|
Types |
Application |
|
Structure Purposes |
General structure and mechanical |
|
Liquid Services |
Petroleum, gas and other fluids conveying |
|
Low and Medium Pressure Boiler Tube |
Steam and boiler manufacturing |
|
Hydraulic Pillar Service |
Hydraulic support |
|
Auto Semi-shaft Casing |
Auto sem-shaft casing |
|
Line Pipe |
Oil and gas conveying |
|
Tubing and Casing |
Oil and gas conveying |
|
Drill Pipes |
Well drilling |
|
Geological Drilling Pipe |
Geological drilling |
|
Furnace tubes, heat exchangers tubes |
Furnace tubes, heat exchangers |
|
Chilled water pipe |
Steam/condensate pipe |
Heat exchanger pipe |
Marine/offshore pipe |
Dredging pipe |
Industrial pipe |
|
Oil and gas pipe |
Fire fighting pipe |
Construction/structure pipe |
Irrigation pipe |
Drain/sewage pipe |
Boiler tube |
Propriétés chimiques %
|
/ |
Grade |
C,
Max
|
Mn,
Max
|
P,
Max
|
S,
Max
|
Cu *,
Max
|
Ni *,
Max
|
Cr *,
Max
|
Mo *,
Max
|
V *,
Max
|
|
Type S (sans soudure) |
A | 0.25 | 0.95 |
0.05 |
0.05 |
0.4 |
0.4 |
0.4 |
0.15 | 0.08 |
| B | 0.3 | 1.2 |
0.05 |
0.05 |
0.4 |
0.4 |
0.4 |
0.15 |
0.08 |
|
|
Type E (résistance électrique soudée) |
A | 0.25 |
0.95 |
0.05 |
0.05 |
0.4 |
0.4 |
0.4 |
0.15 |
0.08 |
| B | 0.3 | 1.2 |
0.05 |
0.05 |
0.4 |
0.4 |
0.4 |
0.15 |
0.08 |
|
|
Type F (Soudé au four) |
A | 0.3 | 1.2 |
0.05 |
0.05 |
0.4 |
0.4 |
0.4 |
0.15 |
0.08 |
* La composition totale de ces cinq éléments ne doit pas dépasser 1,00%
Propriétés mécaniques
|
|
Grade A |
Grade B |
|
Résistance à la traction, min., psi, (MPa) |
48 000 (330) |
60 000 (415) |
|
Force d'élasticité, min., psi, (MPa) |
30 000 (205) |
35 000 (240) |
(Remarque: Il s'agit d'informations résumées de la spécification ASME A53. Veuillez se référer à la norme ou à la spécification spécifique ou contactez-nous pour plus de détails.
English
Español
Français
بالعربية
