Plaque en acier & Poutre

Structural H Poutre, H Poutre, H section, Structural Steel I Beam/acier I-poutres/I poutres inoxydable I-faisceau
H Beam & I Beam

H Beam & I Beam

Type de tuyau:Poutre H structurelle, poutre en H, section H, poutre en H en acier au carbone, poutre en H en acier inoxydable, poutre en H galvanisée, poutre en H en aluminium, poutre en H en alliage, poutre à large bride, poutres en H à haute spécification, poutres en H à motifs, l'acier structurel I Beam/I-Beams d'acier/I rayonne la I-Beam inoxydable

Taille:100*50-700*300mm; Épaisseur de Web: 5-16mm; Largeur de Web: 50 -- 300mm; Épaisseur de bride: 4.5-23mm; Largeur de bride: 50-400mm; Longueur: 1-12m ou comme demande de client

Standard:Aisi,Astm,Din,Jis,Gb ,Jis,Sus,En,Bs Iso.Etc

Forme:Canal H/Canal I

Technique:Laminé à chaud/laminé à froid/galvanisé

Bord:Bord de moulin/bord de limon

Traitement de surface:Galvanisé à chaud, peinture ou noir.

Application: Construction, Décoration, Navire, Équipement médical, Machinerie, Mécanique et fabrication, Structure en acier, Construction navale, Pontage, Châssis automobile

  • H Beam & I Beam
  • H Beam & I Beam
  • H Beam & I Beam
  • H Beam & I Beam
  • Description
  • Spécifications
  • Norme
  • Processus
  • Emballage

Description

Type de tuyau: poutre en H structurelle, poutre en H, section en H, poutre en H en acier au carbone, poutre en H en acier inoxydable, poutre en H galvanisée, poutre en H en aluminium, poutre en H en alliage, poutre à large bride, poutres en H à haute spécification, poutres en H à motifs

Taille: 100*50-700*300mm
Épaisseur de Web: 5-16mm
Largeur de Web: 50 -- 300mm
Épaisseur de bride: 4.5-23mm
Largeur de bride: 50-400mm
Longueur: 1-12m ou comme demande de client
Norme: Aisi,Astm,Din,Jis,Gb ,Jis,Sus,En,Bs Iso.Etc
Forme: H Canal/I Canal
Technique: Laminé à chaud/laminé à froid/galvanisé
Bord: Bord de moulin/bord de limon
Traitement de surface: Galvanisé à chaud, peinture ou noir.
Application:Construction, Décoration, Navire, Équipement médical, Machinerie, Mécanique et fabrication, Structure métallique, Construction navale, Pontage, Châssis d'automobile
Catégorie en acier:
Mn150 1015,1020,1035,1045,1055,1060,1213,1140,1215,9255, C262,1039, 1025,1335,1330,1050,1095,4520,2515,3135,3415,3310, 9840,8630, 8740,4130 k44340, 5015,435 k115, 5115, 5115, 51550 40mn4 12cr1mov Cr5mo 15crmo 30crmo 40crmo 20simn 12cr1movg 20crnimo 15crmog A3642crmo 40crnimoa 50crv


Type de produit: Acier de construction I Beam/poutres en I d'acier/I Beams I-Beam inoxydable

Longueur: 1-12m, répondre à vos exigences.
Hauteur: 100mm-320mm
Largeur: 37mm-132mm ou comme demande du client
Épaisseur: 4.5mm-11.5mm
Tolérance: ± 0.05mm
Norme: Astm, Jis, Din En,Gb,Aisi ,Bs
Matériel: St37,St52,St35,Ss400,S235jr,S355jr,A36 etc.
Tolérance: Épaisseur: ± 0.05mm
Technique: Laminé à chaud
Traitement de surface: Noir, galvanisé, enduit, peint ou en tant que votre demande
Service de traitement: Peinture, enduit, Cuttung, flexion, poinçonnage
Application: Très utilisé dans diverses structures de bâtiment, ponts, véhicules, parenthèse, machines, etc.
Application structurelle de poutre de l'acier I:
Diverses structures de bâtiments civils et industriels; Diverses installations industrielles à grande portée et immeubles modernes de grande hauteur, en particulier des installations industrielles dans des zones à activité sismique fréquente et à conditions de travail à haute température; Ponts à grande échelle nécessitant une grande capacité portante, une bonne stabilité de section et de grandes travées; Équipement lourd; Autoroute; Squelette de navire; appui de mine; Traitement de base et ingénierie de barrage; Divers composants de machine.

Spécifications

Designation
Imperial
(in x lb/ft)


Depth
h
(in)

Width
w
(in)

Web Thickness
tw
(in)

Flange Thickness
tf
(in)

Sectional Area
(in2)

Weight
(lbf/ft)

Static Parameters

Moment of Inertia

Elastic Section Modulus

Ix
(in4)

Iy
(in4)

Sx
(in3)

Sy
(in3)

W 27 x 178

27.8

14.09

0.725

1.190

52.3

178

6990

555

502

78.8

W 27 x 161

27.6

14.02

0.660

1.080

47.4

161

6280

497

455

70.9

W 27 x 146

27.4

14

0.605

0.975

42.9

146

5630

443

411

63.5

W 27 x 114

27.3

10.07

0.570

0.930

33.5

114

4090

159

299

31.5

W 27 x 102

27.1

10.02

0.515

0.830

30.0

102

3620

139

267

27.8

W 27 x 94

26.9

10

0.490

0.745

27.7

94

3270

124

243

24.8

W 27 x 84

26.7

9.96

0.460

0.640

24.8

84

2850

106

213

21.2












W 24 x 162

25

13

0.705

1.220

47.7

162

5170

443

414

68.4

W 24 x 146

24.7

12.9

0.650

1.090

43.0

146

4580

391

371

60.5

W 24 x 131

24.5

12.9

0.605

0.960

38.5

131

4020

340

329

53.0

W 24 x 117

24.3

12.8

0.55

0.850

34.4

117

3540

297

291

46.5

W 24 x 104

24.1

12.75

0.500

0.750

30.6

104

3100

259

258

40.7

W 24 x 94

24.1

9.07

0.515

0.875

27.7

94

2700

109

222

24.0

W 24 x 84

24.1

9.02

0.470

0.770

24.7

84

2370

94.4

196

20.9

W 24 x 76

23.9

9

0.440

0.680

22.4

76

2100

82.5

176

18.4

W 24 x 68

23.7

8.97

0.415

0.585

20.1

68

1830

70.4

154

15.7

W 24 x 62

23.7

7.04

0.430

0.590

18.2

62

1550

34.5

131

9.8

W 24 x 55

23.6

7.01

0.395

0.505

16.2

55

1350

29.1

114

8.3












W 21 x 147

22.1

12.51

0.720

1.150

43.2

147

3630

376

329

60.1

W 21 x 132

21.8

12.44

0.650

1.035

38.8

132

3220

333

295

53.5

W 21 x 122

21.7

12.39

0.600

0.960

35.9

122

2960

305

273

49.2

W 21 x 111

21.5

12.34

0.550

0.875

32.7

111

2670

274

249

44.5

W 21 x 101

21.4

12.29

0.500

0.800

29.8

101

2420

248

227

40.3

W 21 x 93

21.6

8.42

0.580

0.930

27.3

93

2070

92.9

192

22.1

W 21 x 83

21.4

8.36

0.515

0.835

24.3

83

1830

81.4

171

19.5

W 21 x 73

21.2

8.3

0.455

0.740

21.5

73

1600

70.6

151

17.0

W 21 x 68

21.1

8.27

0.430

0.685

20.0

68

1480

64.7

140

15.7

W 21 x 62

21

8.24

0.400

0.615

18.3

62

1330

57.5

127

13.9

W 21 x 57

21.1

6.56

0.405

0.650

16.7

57

1170

30.6

111

9.4

W 21 x 50

20.8

6.53

0.380

0.535

14.7

50

984

24.9

94.5

7.6

W 21 x 44

20.7

6.5

0.350

0.450

13.0

44

843

20.7

81.6

6.4












W 18 x 119

19

11.27

0.655

1.060

35.1

119

2190

253

231

44.9

W 18 x 106

18.7

11.2

0.590

0.940

31.1

106

1910

220

204

39.4

W 18 x 97

18.6

11.15

0.535

0.870

28.5

97

1750

201

188

36.1

W 18 x 86

18.4

11.09

0.480

0.770

25.3

86

1530

175

166

31.6

W 18 x 76

18.2

11.04

0.425

0.680

22.3

76

1330

152

146

27.6

W 18 x 71

18.5

7.64

0.495

0.810

20.8

71

1170

60.3

127

15.8

W 18 x 65

18.4

7.59

0.450

0.750

19.1

65

1070

54.8

117

14.4

W 18 x 60

18.2

7.56

0.415

0.695

17.6

60

984

50.1

108

13.3

W 18 x 55

18.1

7.53

0.390

0.630

16.2

55

890

44.9

98.3

11.9

W 18 x 50

18

7.5

0.355

0.570

14.7

50

800

40.1

88.9

10.7

W 18 x 46

18.1

6.06

0.360

0.605

13.5

46

712

22.5

78.8

7.4

W 18 x 40

17.9

6.02

0.315

0.525

11.8

40

612

19.1

68.4

6.4

W 18 x 35

17.7

6

0.300

0.425

10.3

35

510

15.3

57.6

5.1












W 16 x 100

16.97

10.425

0.585

0.985

29.4

100

1490

186

175

35.7

W 16 x 89

16.75

10.365

0.525

0.875

26.2

89

1300

163

155

31.4

W 16 x 77

16.52

10.295

0.455

0.760

22.6

77

1100

138

134

26.9

W 16 x 67

16.33

10.235

0.395

0.665

19.7

67

954

119

117

23.2

W 16 x 57

16.43

7.120

0.430

0.715

16.8

57

758

43.1

92.2

12.1

W 16 x 50

16.26

7.070

0.380

0.630

14.7

50

659

37.2

81

10.5

W 16 x 45

16.13

7.035

0.345

0.565

13.3

45

586

32.8

72.7

9.3

W 16 x 40

16.01

6.995

0.305

0.505

11.8

40

518

28.9

64.7

8.3

W 16 x 36

15.86

6.985

0.295

0.430

10.6

36

448

24.5

56.5

7

W 16 x 31

15.88

5.525

0.275

0.440

9.12

31

375

12.4

47.2

4.5

W 16 x 26

15.69

5.5

0.250

0.345

7.68

26

301

9.6

38.4

3.5












W 14 x 132

14.66

14.725

0.645

1.030

38.8

132

1530

548

209

74.5

W 14 x 120

14.48

14.670

0.590

0.940

35.3

120

1380

495

190

67.5

W 14 x 109

14.32

14.605

0.525

0.860

32

109

1240

447

173

61.2

W 14 x 99

14.16

14.565

0.485

0.780

29.1

99

1110

402

157

55.2

W 14 x 90

14.02

14.520

0.440

0.710

26.5

90

999

362

143

49.9

W 14 x 82

14.31

10.130

0.510

0.855

24.1

82

882

148

123

29.3

W 14 x 74

14.17

10.070

0.450

0.785

21.8

74

796

134

112

26.6

W 14 x 68

14.04

10.035

0.415

0.720

20.0

68

723

121

103

24.2

W 14 x 61

13.89

9.995

0.375

0.645

17.9

61

640

107

92.2

21.5

W 14 x 53

13.92

8.060

0.370

0.660

15.6

53

541

57.7

77.8

14.3

W 14 x 48

13.79

8.030

0.340

0.595

14.1

48

485

51.4

70.3

12.8

W 14 x 43

13.66

7.995

0.305

0.530

12.6

43

428

45.2

62.7

11.3

W 14 x 38

14.10

6.770

0.310

0.515

11.2

38

385

26.7

54.6

7.9

W 14 x 34

13.98

6.745

0.285

0.455

10.0

34

340

23.3

48.6

6.9

W 14 x 30

13.84

6.730

0.270

0.385

8.85

30

291

19.6

42.0

5.8

W 14 x 26

13.91

5.025

0.255

0.420

7.69

26

245

8.9

35.3

3.5

W 14 x 22

13.74

5

0.230

0.335

6.49

22

199

7

29.0

2.8












W 12 x 136

13.41

12.4

0.79

1.250

39.9

136

1240

398

186

64.2

W 12 x 120

13.12

12.32

0.71

1.105

35.3

120

1070

345

163

56.0

W 12 x 106

12.89

12.22

0.61

0.990

31.2

106

933

301

145

49.3

W 12 x 96

12.71

12.16

0.55

0.900

28.2

96

833

270

131

44.4

W 12 x 87

12.53

12.125

0.515

0.810

25.6

87

740

241

118

39.7

W 12 x 79

12.38

12.08

0.47

0.735

23.2

79

662

216

107

35.8

W 12 x 72

12.25

12.04

0.43

0.670

21.1

72

597

195

97.4

32.4

W 12 x 65

12.12

12

0.39

0.605

19.1

65

533

174

87.9

29.1

W 12 x 58

12.19

10.01

0.36

0.640

17.0

58

475

107

78

21.4

W 12 x 53

12.06

9.995

0.345

0.575

15.6

53

425

95.8

70.6

19.2

W 12 x 50

12.19

8.08

0.37

0.640

14.7

50

394

56.3

64.7

13.9

W 12 x 45

12.06

8.045

0.335

0.575

13.2

45

350

50.0

58.1

12.4

W 12 x 40

11.94

8.005

0.295

0.515

11.8

40

310

44.1

51.9

11.0

W 12 x 35

12.50

6.56

0.3

0.520

10.3

35

285

24.5

45.6

7.5

W 12 x 30

12.34

6.52

0.26

0.440

8.8

30

238

20.3

38.6

6.2

W 12 x 26

12.22

6.490

0.23

0.380

7.7

26

204

17.3

33.4

5.3

W 12 x 22

12.31

4.03

0.26

0.425

6.5

22

156

4.7

25.4

2.3

W 12 x 19

12.16

4.005

0.235

0.350

5.6

19

130

3.8

21.3

1.9

W 12 x 16

11.99

3.990

0.22

0.265

4.7

16

103

2.8

17.1

1.4

W 12 x 14

11.91

3.970

0.2

0.225

4.2

14

88.6

2.4

14.9

1.2












W 10 x 112

11.36

10.415

0.755

1.250

32.9

112

716

236

126

45.3

W 10 x 100

11.1

10.340

0.680

1.1120

29.4

100

623

207

112

40.0

W 10 x 88

10.84

10.265

0.605

0.990

25.9

88

534

179

98.5

34.8

W 10 x 77

10.60

10.190

0.530

0.870

22.6

77

455

154

85.9

30.1

W 10 x 68

10.40

10.130

0.470

0.770

20.0

68

394

134

75.7

26.4

W 10 x 60

10.22

10.080

0.420

0.680

17.6

60

341

116

66.7

23.0

W 10 x 54

10.09

10.030

0.370

0.615

15.8

54

303

103

60.0

20.6

W 10 x 49

9.98

10

0.340

0.560

14.4

49

272

93.4

54.6

18.7

W 10 x 45

10.10

8.020

0.350

0.620

13.3

45

248

53.4

49.1

13.3

W 10 x 39

9.92

7.985

0.315

0.530

11.5

39

209

45.0

42.1

11.3

W 10 x 33

9.73

7.960

0.290

0.435

9.71

33

170

36.6

35.0

9.2

W 10 x 30

10.47

5.81

0.3

0.510

8.84

30

170

16.7

32.4

5.8

W 10 x 26

10.33

5.770

0.26

0.440

7.6

26

144

14.1

27.9

4.9

W 10 x 22

10.17

5.750

0.240

0.360

6.5

22

118

11.4

23.2

4

W 10 x 19

10.24

4.020

0.250

0.395

5.6

19

96.3

4.3

18.8

2.1

W 10 x 17

10.11

4.010

0.240

0.330

5

17

81.9

3.6

16.2

1.8

W 10 x 15

9.99

4

0.230

0.270

4.4

15

68.9

2.9

13.8

1.5

W 10 x 12

9.87

3.960

0.190

0.210

3.5

12

53.8

2.2

10.9

1.1












W 8 x 67

9.00

8.280

0.570

0.935

19.7

67

272

88.6

60.4

21.4

W 8 x 58

8.75

8.220

0.510

0.810

17.1

58

228

75.1

52.0

18.3

W 8 x 48

8.5

8.110

0.400

0.685

14.1

48

184

60.9

43.3

15.0

W 8 x 40

8.25

8.070

0.360

0.560

11.7

40

146

49.1

35.5

12.2

W 8 x 35

8.12

8.020

0.310

0.495

10.3

35

127

42.6

31.2

10.6

W 8 x 31

8.00

7.995

0.285

0.435

9.1

31

110

37.1

27.5

9.3

W 8 x 28

8.06

6.535

0.285

0.465

8.3

28

98.0

21.7

24.3

6.6

W 8 x 24

7.93

6.495

0.245

0.400

7.1

24

82.8

18.3

20.9

5.6

W 8 x 21

8.28

5.270

0.250

0.400

6.2

21

75.3

9.8

18.2

3.7

W 8 x 18

8.14

5.250

0.230

0.330

5.3

18

61.9

8

15.2

3

W 8 x 15

8.11

4.015

0.245

0.315

4.4

15

48.0

3.4

11.8

1.7

W 8 x 13

7.99

4

0.230

0.255

3.8

13

39.6

2.7

9.9

1.4

W 8 x 10

7.89

3.940

0.170

0.205

2.9

10

30.3

2.1

7.8

1.1












W 6 x 25

6.38

6.080

0.320

0.455

7.3

25

53.4

17.1

16.7

5.6

W 6 x 20

6.20

6.020

0.260

0.365

5.9

20

41.4

13.3

13.4

4.4

W 6 x 16

6.28

4.030

0.260

0.405

4.7

16

32.1

4.4

10.2

2.2

W 6 x 15

5.99

5.990

0.230

0.260

4.4

15

29.1

9.3

9.7

3.1

W 6 x 12

6.03

4

0.230

0.280

3.6

12

22.1

3

7.3

1.5

W 6 x 9

5.90

3.940

0.170

0.215

2.7

9

16.4

2.2

5.6

1.1












W 5 x 19

5.15

5.030

0.270

0.430

5.5

19

26.2

9.1

10.2

3.6

W 5 x 16

5.01

5

0.240

0.360

4.7

16

21.3

7.5

8.5

3












W 4 x 13

4.16

4.060

0.280

0.345

3.8

13

11.3

3.9

5.5

1.9

Norme

Aisi, astm,din,jis,gb ,jis,sus,en,bs iso.etc

Processus

Emballage

Spécifications

Designation
Imperial
(in x lb/ft)


Depth
h
(in)

Width
w
(in)

Web Thickness
tw
(in)

Flange Thickness
tf
(in)

Sectional Area
(in2)

Weight
(lbf/ft)

Static Parameters

Moment of Inertia

Elastic Section Modulus

Ix
(in4)

Iy
(in4)

Sx
(in3)

Sy
(in3)

W 27 x 178

27.8

14.09

0.725

1.190

52.3

178

6990

555

502

78.8

W 27 x 161

27.6

14.02

0.660

1.080

47.4

161

6280

497

455

70.9

W 27 x 146

27.4

14

0.605

0.975

42.9

146

5630

443

411

63.5

W 27 x 114

27.3

10.07

0.570

0.930

33.5

114

4090

159

299

31.5

W 27 x 102

27.1

10.02

0.515

0.830

30.0

102

3620

139

267

27.8

W 27 x 94

26.9

10

0.490

0.745

27.7

94

3270

124

243

24.8

W 27 x 84

26.7

9.96

0.460

0.640

24.8

84

2850

106

213

21.2












W 24 x 162

25

13

0.705

1.220

47.7

162

5170

443

414

68.4

W 24 x 146

24.7

12.9

0.650

1.090

43.0

146

4580

391

371

60.5

W 24 x 131

24.5

12.9

0.605

0.960

38.5

131

4020

340

329

53.0

W 24 x 117

24.3

12.8

0.55

0.850

34.4

117

3540

297

291

46.5

W 24 x 104

24.1

12.75

0.500

0.750

30.6

104

3100

259

258

40.7

W 24 x 94

24.1

9.07

0.515

0.875

27.7

94

2700

109

222

24.0

W 24 x 84

24.1

9.02

0.470

0.770

24.7

84

2370

94.4

196

20.9

W 24 x 76

23.9

9

0.440

0.680

22.4

76

2100

82.5

176

18.4

W 24 x 68

23.7

8.97

0.415

0.585

20.1

68

1830

70.4

154

15.7

W 24 x 62

23.7

7.04

0.430

0.590

18.2

62

1550

34.5

131

9.8

W 24 x 55

23.6

7.01

0.395

0.505

16.2

55

1350

29.1

114

8.3












W 21 x 147

22.1

12.51

0.720

1.150

43.2

147

3630

376

329

60.1

W 21 x 132

21.8

12.44

0.650

1.035

38.8

132

3220

333

295

53.5

W 21 x 122

21.7

12.39

0.600

0.960

35.9

122

2960

305

273

49.2

W 21 x 111

21.5

12.34

0.550

0.875

32.7

111

2670

274

249

44.5

W 21 x 101

21.4

12.29

0.500

0.800

29.8

101

2420

248

227

40.3

W 21 x 93

21.6

8.42

0.580

0.930

27.3

93

2070

92.9

192

22.1

W 21 x 83

21.4

8.36

0.515

0.835

24.3

83

1830

81.4

171

19.5

W 21 x 73

21.2

8.3

0.455

0.740

21.5

73

1600

70.6

151

17.0

W 21 x 68

21.1

8.27

0.430

0.685

20.0

68

1480

64.7

140

15.7

W 21 x 62

21

8.24

0.400

0.615

18.3

62

1330

57.5

127

13.9

W 21 x 57

21.1

6.56

0.405

0.650

16.7

57

1170

30.6

111

9.4

W 21 x 50

20.8

6.53

0.380

0.535

14.7

50

984

24.9

94.5

7.6

W 21 x 44

20.7

6.5

0.350

0.450

13.0

44

843

20.7

81.6

6.4












W 18 x 119

19

11.27

0.655

1.060

35.1

119

2190

253

231

44.9

W 18 x 106

18.7

11.2

0.590

0.940

31.1

106

1910

220

204

39.4

W 18 x 97

18.6

11.15

0.535

0.870

28.5

97

1750

201

188

36.1

W 18 x 86

18.4

11.09

0.480

0.770

25.3

86

1530

175

166

31.6

W 18 x 76

18.2

11.04

0.425

0.680

22.3

76

1330

152

146

27.6

W 18 x 71

18.5

7.64

0.495

0.810

20.8

71

1170

60.3

127

15.8

W 18 x 65

18.4

7.59

0.450

0.750

19.1

65

1070

54.8

117

14.4

W 18 x 60

18.2

7.56

0.415

0.695

17.6

60

984

50.1

108

13.3

W 18 x 55

18.1

7.53

0.390

0.630

16.2

55

890

44.9

98.3

11.9

W 18 x 50

18

7.5

0.355

0.570

14.7

50

800

40.1

88.9

10.7

W 18 x 46

18.1

6.06

0.360

0.605

13.5

46

712

22.5

78.8

7.4

W 18 x 40

17.9

6.02

0.315

0.525

11.8

40

612

19.1

68.4

6.4

W 18 x 35

17.7

6

0.300

0.425

10.3

35

510

15.3

57.6

5.1












W 16 x 100

16.97

10.425

0.585

0.985

29.4

100

1490

186

175

35.7

W 16 x 89

16.75

10.365

0.525

0.875

26.2

89

1300

163

155

31.4

W 16 x 77

16.52

10.295

0.455

0.760

22.6

77

1100

138

134

26.9

W 16 x 67

16.33

10.235

0.395

0.665

19.7

67

954

119

117

23.2

W 16 x 57

16.43

7.120

0.430

0.715

16.8

57

758

43.1

92.2

12.1

W 16 x 50

16.26

7.070

0.380

0.630

14.7

50

659

37.2

81

10.5

W 16 x 45

16.13

7.035

0.345

0.565

13.3

45

586

32.8

72.7

9.3

W 16 x 40

16.01

6.995

0.305

0.505

11.8

40

518

28.9

64.7

8.3

W 16 x 36

15.86

6.985

0.295

0.430

10.6

36

448

24.5

56.5

7

W 16 x 31

15.88

5.525

0.275

0.440

9.12

31

375

12.4

47.2

4.5

W 16 x 26

15.69

5.5

0.250

0.345

7.68

26

301

9.6

38.4

3.5












W 14 x 132

14.66

14.725

0.645

1.030

38.8

132

1530

548

209

74.5

W 14 x 120

14.48

14.670

0.590

0.940

35.3

120

1380

495

190

67.5

W 14 x 109

14.32

14.605

0.525

0.860

32

109

1240

447

173

61.2

W 14 x 99

14.16

14.565

0.485

0.780

29.1

99

1110

402

157

55.2

W 14 x 90

14.02

14.520

0.440

0.710

26.5

90

999

362

143

49.9

W 14 x 82

14.31

10.130

0.510

0.855

24.1

82

882

148

123

29.3

W 14 x 74

14.17

10.070

0.450

0.785

21.8

74

796

134

112

26.6

W 14 x 68

14.04

10.035

0.415

0.720

20.0

68

723

121

103

24.2

W 14 x 61

13.89

9.995

0.375

0.645

17.9

61

640

107

92.2

21.5

W 14 x 53

13.92

8.060

0.370

0.660

15.6

53

541

57.7

77.8

14.3

W 14 x 48

13.79

8.030

0.340

0.595

14.1

48

485

51.4

70.3

12.8

W 14 x 43

13.66

7.995

0.305

0.530

12.6

43

428

45.2

62.7

11.3

W 14 x 38

14.10

6.770

0.310

0.515

11.2

38

385

26.7

54.6

7.9

W 14 x 34

13.98

6.745

0.285

0.455

10.0

34

340

23.3

48.6

6.9

W 14 x 30

13.84

6.730

0.270

0.385

8.85

30

291

19.6

42.0

5.8

W 14 x 26

13.91

5.025

0.255

0.420

7.69

26

245

8.9

35.3

3.5

W 14 x 22

13.74

5

0.230

0.335

6.49

22

199

7

29.0

2.8












W 12 x 136

13.41

12.4

0.79

1.250

39.9

136

1240

398

186

64.2

W 12 x 120

13.12

12.32

0.71

1.105

35.3

120

1070

345

163

56.0

W 12 x 106

12.89

12.22

0.61

0.990

31.2

106

933

301

145

49.3

W 12 x 96

12.71

12.16

0.55

0.900

28.2

96

833

270

131

44.4

W 12 x 87

12.53

12.125

0.515

0.810

25.6

87

740

241

118

39.7

W 12 x 79

12.38

12.08

0.47

0.735

23.2

79

662

216

107

35.8

W 12 x 72

12.25

12.04

0.43

0.670

21.1

72

597

195

97.4

32.4

W 12 x 65

12.12

12

0.39

0.605

19.1

65

533

174

87.9

29.1

W 12 x 58

12.19

10.01

0.36

0.640

17.0

58

475

107

78

21.4

W 12 x 53

12.06

9.995

0.345

0.575

15.6

53

425

95.8

70.6

19.2

W 12 x 50

12.19

8.08

0.37

0.640

14.7

50

394

56.3

64.7

13.9

W 12 x 45

12.06

8.045

0.335

0.575

13.2

45

350

50.0

58.1

12.4

W 12 x 40

11.94

8.005

0.295

0.515

11.8

40

310

44.1

51.9

11.0

W 12 x 35

12.50

6.56

0.3

0.520

10.3

35

285

24.5

45.6

7.5

W 12 x 30

12.34

6.52

0.26

0.440

8.8

30

238

20.3

38.6

6.2

W 12 x 26

12.22

6.490

0.23

0.380

7.7

26

204

17.3

33.4

5.3

W 12 x 22

12.31

4.03

0.26

0.425

6.5

22

156

4.7

25.4

2.3

W 12 x 19

12.16

4.005

0.235

0.350

5.6

19

130

3.8

21.3

1.9

W 12 x 16

11.99

3.990

0.22

0.265

4.7

16

103

2.8

17.1

1.4

W 12 x 14

11.91

3.970

0.2

0.225

4.2

14

88.6

2.4

14.9

1.2












W 10 x 112

11.36

10.415

0.755

1.250

32.9

112

716

236

126

45.3

W 10 x 100

11.1

10.340

0.680

1.1120

29.4

100

623

207

112

40.0

W 10 x 88

10.84

10.265

0.605

0.990

25.9

88

534

179

98.5

34.8

W 10 x 77

10.60

10.190

0.530

0.870

22.6

77

455

154

85.9

30.1

W 10 x 68

10.40

10.130

0.470

0.770

20.0

68

394

134

75.7

26.4

W 10 x 60

10.22

10.080

0.420

0.680

17.6

60

341

116

66.7

23.0

W 10 x 54

10.09

10.030

0.370

0.615

15.8

54

303

103

60.0

20.6

W 10 x 49

9.98

10

0.340

0.560

14.4

49

272

93.4

54.6

18.7

W 10 x 45

10.10

8.020

0.350

0.620

13.3

45

248

53.4

49.1

13.3

W 10 x 39

9.92

7.985

0.315

0.530

11.5

39

209

45.0

42.1

11.3

W 10 x 33

9.73

7.960

0.290

0.435

9.71

33

170

36.6

35.0

9.2

W 10 x 30

10.47

5.81

0.3

0.510

8.84

30

170

16.7

32.4

5.8

W 10 x 26

10.33

5.770

0.26

0.440

7.6

26

144

14.1

27.9

4.9

W 10 x 22

10.17

5.750

0.240

0.360

6.5

22

118

11.4

23.2

4

W 10 x 19

10.24

4.020

0.250

0.395

5.6

19

96.3

4.3

18.8

2.1

W 10 x 17

10.11

4.010

0.240

0.330

5

17

81.9

3.6

16.2

1.8

W 10 x 15

9.99

4

0.230

0.270

4.4

15

68.9

2.9

13.8

1.5

W 10 x 12

9.87

3.960

0.190

0.210

3.5

12

53.8

2.2

10.9

1.1












W 8 x 67

9.00

8.280

0.570

0.935

19.7

67

272

88.6

60.4

21.4

W 8 x 58

8.75

8.220

0.510

0.810

17.1

58

228

75.1

52.0

18.3

W 8 x 48

8.5

8.110

0.400

0.685

14.1

48

184

60.9

43.3

15.0

W 8 x 40

8.25

8.070

0.360

0.560

11.7

40

146

49.1

35.5

12.2

W 8 x 35

8.12

8.020

0.310

0.495

10.3

35

127

42.6

31.2

10.6

W 8 x 31

8.00

7.995

0.285

0.435

9.1

31

110

37.1

27.5

9.3

W 8 x 28

8.06

6.535

0.285

0.465

8.3

28

98.0

21.7

24.3

6.6

W 8 x 24

7.93

6.495

0.245

0.400

7.1

24

82.8

18.3

20.9

5.6

W 8 x 21

8.28

5.270

0.250

0.400

6.2

21

75.3

9.8

18.2

3.7

W 8 x 18

8.14

5.250

0.230

0.330

5.3

18

61.9

8

15.2

3

W 8 x 15

8.11

4.015

0.245

0.315

4.4

15

48.0

3.4

11.8

1.7

W 8 x 13

7.99

4

0.230

0.255

3.8

13

39.6

2.7

9.9

1.4

W 8 x 10

7.89

3.940

0.170

0.205

2.9

10

30.3

2.1

7.8

1.1












W 6 x 25

6.38

6.080

0.320

0.455

7.3

25

53.4

17.1

16.7

5.6

W 6 x 20

6.20

6.020

0.260

0.365

5.9

20

41.4

13.3

13.4

4.4

W 6 x 16

6.28

4.030

0.260

0.405

4.7

16

32.1

4.4

10.2

2.2

W 6 x 15

5.99

5.990

0.230

0.260

4.4

15

29.1

9.3

9.7

3.1

W 6 x 12

6.03

4

0.230

0.280

3.6

12

22.1

3

7.3

1.5

W 6 x 9

5.90

3.940

0.170

0.215

2.7

9

16.4

2.2

5.6

1.1












W 5 x 19

5.15

5.030

0.270

0.430

5.5

19

26.2

9.1

10.2

3.6

W 5 x 16

5.01

5

0.240

0.360

4.7

16

21.3

7.5

8.5

3












W 4 x 13

4.16

4.060

0.280

0.345

3.8

13

11.3

3.9

5.5

1.9

Norme

Aisi, astm,din,jis,gb ,jis,sus,en,bs iso.etc

Processus

Emballage

Si vous avez n'importe quelles enquêtes et questions, svp contactez-nous à tout moment. Merci d'avance. Bienvenue!
