Copper tubes play a vital role in the construction of heat exchangers and locomotive systems. Known for their superior performance at elevated temperatures, copper outperforms most other metals in thermal applications. Its key advantages—exceptional resistance to corrosion, erosion, and oxidation—make it an ideal material for high-efficiency and long-lasting tube systems.
Thanks to its durability, thermal conductivity, and cost-effectiveness, copper has become a preferred choice in these industries. With advancements in manufacturing technology, modern copper tubes can now be used to create smaller, lighter, and stronger copper radiators. These new-generation radiators are environmentally friendly, as they are lead-free and manufactured through cleaner, more efficient processes.
Made using a non-toxic, low-temperature alloy based on the CuNiSnP system, these copper tubes can be brazed in the same vacuum or controlled-atmosphere furnaces used for aluminum radiators—at around 600°C. Since no flux is needed in the brazing process, there’s no requirement for post-braze cleaning, and the final product is free from hazardous residues.
Below are the technical specifications and dimensional details of copper tubes used in heat exchangerand locomotives applications.
Super Steel Manufacturing Co.,Ltd is professional copper pipes manufacturer, for more details, please contact:sales@super-steels.com
Technical Specification of Heat Exchanger and Locomotives Copper Tubes
|
Standard |
ASTM B68 / ASTM B75 / ASTM B280 / ASTM B88 / JIS H 3300 / EN1057 or BS2871: PART 2:1972 / DIN 1754/8905/ IS2501 |
|
Specification |
ASTM B280, JIS H3300, AS/NZS1571.JIS3300-2006 |
|
Description |
Copper Pipe and Tube For Heat Exchangers & Locomotives |
|
Material |
TU2, C1020T, C10200, T2, C1100, TP1, C1201T, C1200, TP2, C1220T, C12200, C14200, C19400, etc |
|
Outer Diameter(OD) |
4mm to 150mm |
|
Wall Thickness : |
0.2mm~5mm |
|
Length |
1m, 2m, 3m, 6m, or as required. |
|
Types |
Seamless Pipes, Tube / Inner Grooved Pipes / Square Pipes, Tube / Rectangular Pipes, Tube / Finned Pipes, Tube |
|
Application |
1. Pancake Coil for ACR, General Engineering Applications |
Dimensions of Heat Exchanger and Locomotives Copper Tubes
Wall thickness of copper pipe varies with the pipe schedule - the four common standards are named K, L, M, and DWV (Drain/Waste/Vent - non-pressurized), from thickest to thinnest.
|
Pipe / Tube Type |
Nominal |
O.D. |
I.D. |
Wall Thickness |
||||||
|
K |
L |
M |
DWV |
K |
L |
M |
DWV |
|||
|
Copper Tubes for Heat Exchangers |
1/4" |
3/8" |
0.305 |
0.315 |
- |
- |
0.035 |
0.030 |
- |
- |
|
Copper Tubes for Heat Exchangers |
3/8" |
1/2" |
0.402 |
0.430 |
0.450 |
- |
0.049 |
0.035 |
0.025 |
- |
|
Copper Tubes for Heat Exchangers |
1/2" |
5/8" |
0.527 |
0.545 |
0.569 |
- |
0.049 |
0.040 |
0.028 |
- |
|
Copper Tubes for Heat Exchangers |
5/8" |
3/4" |
0.652 |
0.666 |
- |
- |
0.049 |
0.042 |
- |
- |
|
Copper Tubes for Heat Exchangers |
3/4" |
7/8" |
0.745 |
0.785 |
0.811 |
- |
0.065 |
0.045 |
0.032 |
- |
|
Copper Tubes for Heat Exchangers |
1" |
1-1/8" |
0.995 |
1.025 |
1.055 |
- |
0.065 |
0.050 |
0.035 |
- |
|
Copper Tubes for Heat Exchangers |
1-1/4" |
1-3/8" |
1.245 |
1.265 |
1.291 |
1.295 |
0.065 |
0.055 |
0.042 |
0.040 |
|
Copper Tubes for Heat Exchangers |
1-1/2" |
1-5/8" |
1.481 |
1.505 |
1.527 |
1.541 |
0.072 |
0.060 |
0.049 |
0.042 |
|
Copper Tubes for Heat Exchangers |
2" |
2-1/8" |
1.959 |
1.985 |
2.009 |
2.041 |
0.083 |
0.070 |
0.058 |
0.042 |
|
Copper Tubes for Heat Exchangers |
2-1/2" |
2-5/8" |
2.435 |
2.465 |
2.495 |
- |
0.095 |
0.080 |
0.065 |
- |
|
Copper Tubes for Heat Exchangers |
3" |
3-1/8" |
2.907 |
2.945 |
2.981 |
3.030 |
0.109 |
0.090 |
0.072 |
0.045 |
Common wall-thicknesses of copper tubing in the USA are "Type K", "Type L", "Type M", and "Type DWV"
Common wall-thicknesses in Europe are "Type X", "Type Y" and "Type Z", defined by the EN 1057 standard.
