Pipe Fittings

Pipe End Cap, Pipe Steel Cap, Standard Steel Pipe Cap, Strong Steel Pipe Cap

Cap

Product Type: Pipe End Cap, Pipe Steel Cap, Standard Steel Pipe Cap, Strong Steel Pipe Cap
Size：1/2"-48"/(Dn15-Dn1200)
Connection： Welding
Technic：Forged
Varieties：Sch10，Sch20, Sgp, Std, Sch40, Sch80, Sch160
Material：Carbon Steel: Astm A234 Gr Wpb , St37.2 , St35.8……
Alloy Steel:A234 Wp5/Wp9/Wp11/Wp22/Wp91, A420 Wpl6, A860 Whpy 42/52/60/65/70/80……
Stainless Steel: A403 Wp304/Tp304 , Wp304l/Tp304l , Wp316/Tp316 , Wp316l/Tp316l, Wp321/Tp321 , Wp310/Wpba234,,A403-Wp316,A403-Wp316l,A403-Wp317,A403-Wp321 Etc.
Standard：Bs, Din ,Jis,Etc. Ansi B16.9/16.28, Astm,Api 5l, Din2605/2615/2616, Jis2311/Jis 2312/Jis2313/ Asme B36.10m---1996,Mss Sp43/Mss P75/ Din2617 /Gb-12459/Gb-T13401 Etc…
Surface Treatment：Black Rust-Proof Oil, Transparent Oil, Shot Blasted, Black Painting, Rust-Proof Oil, Transparent Oil, Galvanizing,, Hot Galvanizing
Application ：Petroleum, Electricity, Chemicals, Natural Gas, Construction, Shipbuilding And Other Fields Because Of Its High Pressure, High Temperature, Etc

Inquiry

Send Email

Description
Specification
Standard
Process
Packing

Description

TypeName:cap, enc cap, pipe cap, seamless cap , butt welding cap, carbon steel cap(CS cap), mild steel cap(MS cap), alloy steel cap(AS cap), stainless steel cap(SS cap) Semi Ellipsoidal,

semi ellipsoid cap ,Cap Ellipsoid ,Ellipsoid Cap ,Semi-spherical Head

Size：1/2"-48"/(DN15-DN1200)

Connection： welding

Technic：forged

Varieties：SCH10，SCH20, SGP, STD, SCH40, SCH80, SCH160

Material：

carbon steel: ASTM A234 GR WPB , ST37.2 , ST35.8……

alloy steel: A234 WP5/WP9/WP11/WP22/WP91, A420 WPL6, A860 WHPY 42/52/60/65/70/80……

stainless steel: A403 WP304/TP304 , WP304L/TP304L , WP316/TP316 , WP316L/TP316L, WP321/TP321 , WP310/

WPBA234,,A403-WP316,A403-WP316L,A403-WP317,A403-WP321 etc.

Standard：BS, DIN ,JIS,etc. ANSI B16.9/16.28, ASTM,API 5L, DIN2605/2615/2616, JIS2311/JIS 2312/JIS2313/ ASME B36.10M---1996,MSS SP43/MSS P75/ DIN2617 /GB-12459/GB-T13401 etc…

Surface treatment：Black rust-proof oil, transparent oil, Shot blasted, black painting, rust-proof oil, transparent oil, galvanizing,, hot galvanizing

Application ：petroleum, electricity, chemicals, natural gas, construction, shipbuilding and other fields because of its high pressure, high temperature, etc

Pipe Cap Material Grades:

Stainless Steel Pipe Cap：ASTM A403 WP Gr. 304, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L

Carbon Steel Pipe Cap：ASTM A 234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.

Low Temperature Carbon Steel Pipe Cap：ASTM A420 WPL3, A420 WPL6

Alloy Steel Pipe Cap：ASTM / ASME A/SA 234 Gr. WP 1, WP 5, WP 9, WP 11, WP 12, WP 22, WP 91

Duplex Pipe Cap：ASTM A 815, ASME SA 815 UNS NO S31803, S32205. Werkstoff No. 1.4462

Nickel Alloy Pipe Cap：ASTM / ASME SB 336 UNS 2200 ( NICKEL 200 ), UNS 2201 (NICKEL 201 ), UNS 4400 (MONEL 400 ), UNS 8020 ( ALLOY 20 / 20 CB 3, UNS 8825 INCONEL (825), UNS 6600 (INCONEL 600 ), UNS 6601 ( INCONEL 601 ), UNS 6625 (INCONEL 625), UNS 10276 ( HASTELLOY C 276 )

Specification

Size

Buttweld Cap

DN	NPS	OD	E	E1
15	1/2	21.3	25	25
20	3/4	26.7	25	25
25	1	33.4	38	38
32	1 1/4	42.2	38	38
40	1 1/2	48.3	38	38
50	2	60.3	38	44
65	2 1/2	73	38	51
80	3	88.9	51	64
90	3 1/2	101.6	64	76
100	4	114.3	64	76
125	5	141.3	76	89
150	6	168.3	89	102
200	8	219.1	102	127
250	10	273	127	152
300	12	323.9	152	178
350	14	355.6	165	191
400	16	406.4	178	203
450	18	457	203	229
500	20	508	229	254
550	22	558.8	254	254
600	24	609.6	267	305
650	26	660.4	267	–
700	28	711.2	267	–
750	30	762	267	–
800	32	812.8	267	–
850	34	863.6	267	–
900	36	914.4	267	–
950	38	965.2	305	–
1000	40	1016	305	–
1050	42	1066.8	305	–
1100	44	1117.8	343	–
1150	46	1168.4	343	–
1200	48	1219.2	343	–

socket weld cap

DN	NPS	B	C						J	K
			3000		6000		9000			3000	6000	9000
			ave	min	ave	min	ave	min		3000	6000	9000
6	1/8	10.9	3.18	3.18	3.96	3.43			9.5	4.8	6.4
8	1/4	14.3	3.78	3.3	4.6	4.01			9.5	4.8	6.4
10	3/8	17.7	4.01	3.5	5.03	4.37			9.5	4.8	6.4
15	1/2	21.9	4.67	4.09	5.97	5.18	9.53	8.18	9.5	6.4	7.9	11.2
20	3/4	27.3	4.9	4.27	6.96	6.04	9.78	8.56	12.5	6.4	7.9	12.7
25	1	34	5.69	4.98	7.92	6.93	11.38	9.96	12.5	9.6	11.2	14.2
32	1 1/4	42.8	6.07	5.28	7.92	6.93	12.14	10.62	12.5	9.6	11.2	14.2
40	1 1/2	48.9	6.35	5.54	8.92	7.8	12.7	11.12	12.5	11.2	12.7	15.7
50	2	61.2	6.93	6.04	10.92	9.5	13.84	12.12	16	12.7	15.7	19
65	2 1/2	73.9	8.76	7.62					16	15.7	19
80	3	89.9	9.52	8.3					16	19	22.4
100	4	115.5	10.69	9.35					19	22.4	28.4

Threaded Cap

DN	NPS	P		D		G		L5	L2
DN	NPS	3000	6000	3000	6000	3000	6000	L5	L2
6	1/8	19	–	16	22	4.8	–	6.4	6.7
8	1/4	25	27	19	25	4.8	6.4	8.1	10.2
10	3/8	25	27	22	32	4.8	6.4	9.1	10.4
15	1/2	32	33	28	38	6.4	7.9	10.9	13.6
20	3/4	37	38	35	44	6.4	7.9	12.7	13.9
25	1	41	43	44	57	9.7	11.2	14.7	17.3
32	1 1/4	44	46	57	64	9.7	11.2	17	18
40	1 1/2	44	48	64	76	11.2	12.7	17.8	18.4
50	2	48	51	76	92	12.7	15.7	19	19.2
65	2 1/2	60	64	92	108	15.7	19	23.6	28.9
80	3	65	68	108	127	19	22.4	25.9	30.5
100	4	68	75	140	159	22.4	28.4	27.7	33

Standard

astm, ansi, api, etc.

Process

UNS32750 UNS32760 Stainless Steel Pipe fittings Cap 4'' Sch10s To SCH160S ASME B16.9 stainless steel dished head

Packing

Specification

Size

Buttweld Cap

DN	NPS	OD	E	E1
15	1/2	21.3	25	25
20	3/4	26.7	25	25
25	1	33.4	38	38
32	1 1/4	42.2	38	38
40	1 1/2	48.3	38	38
50	2	60.3	38	44
65	2 1/2	73	38	51
80	3	88.9	51	64
90	3 1/2	101.6	64	76
100	4	114.3	64	76
125	5	141.3	76	89
150	6	168.3	89	102
200	8	219.1	102	127
250	10	273	127	152
300	12	323.9	152	178
350	14	355.6	165	191
400	16	406.4	178	203
450	18	457	203	229
500	20	508	229	254
550	22	558.8	254	254
600	24	609.6	267	305
650	26	660.4	267	–
700	28	711.2	267	–
750	30	762	267	–
800	32	812.8	267	–
850	34	863.6	267	–
900	36	914.4	267	–
950	38	965.2	305	–
1000	40	1016	305	–
1050	42	1066.8	305	–
1100	44	1117.8	343	–
1150	46	1168.4	343	–
1200	48	1219.2	343	–

socket weld cap

DN	NPS	B	C						J	K
			3000		6000		9000			3000	6000	9000
			ave	min	ave	min	ave	min		3000	6000	9000
6	1/8	10.9	3.18	3.18	3.96	3.43			9.5	4.8	6.4
8	1/4	14.3	3.78	3.3	4.6	4.01			9.5	4.8	6.4
10	3/8	17.7	4.01	3.5	5.03	4.37			9.5	4.8	6.4
15	1/2	21.9	4.67	4.09	5.97	5.18	9.53	8.18	9.5	6.4	7.9	11.2
20	3/4	27.3	4.9	4.27	6.96	6.04	9.78	8.56	12.5	6.4	7.9	12.7
25	1	34	5.69	4.98	7.92	6.93	11.38	9.96	12.5	9.6	11.2	14.2
32	1 1/4	42.8	6.07	5.28	7.92	6.93	12.14	10.62	12.5	9.6	11.2	14.2
40	1 1/2	48.9	6.35	5.54	8.92	7.8	12.7	11.12	12.5	11.2	12.7	15.7
50	2	61.2	6.93	6.04	10.92	9.5	13.84	12.12	16	12.7	15.7	19
65	2 1/2	73.9	8.76	7.62					16	15.7	19
80	3	89.9	9.52	8.3					16	19	22.4
100	4	115.5	10.69	9.35					19	22.4	28.4

Threaded Cap

DN	NPS	P		D		G		L5	L2
DN	NPS	3000	6000	3000	6000	3000	6000	L5	L2
6	1/8	19	–	16	22	4.8	–	6.4	6.7
8	1/4	25	27	19	25	4.8	6.4	8.1	10.2
10	3/8	25	27	22	32	4.8	6.4	9.1	10.4
15	1/2	32	33	28	38	6.4	7.9	10.9	13.6
20	3/4	37	38	35	44	6.4	7.9	12.7	13.9
25	1	41	43	44	57	9.7	11.2	14.7	17.3
32	1 1/4	44	46	57	64	9.7	11.2	17	18
40	1 1/2	44	48	64	76	11.2	12.7	17.8	18.4
50	2	48	51	76	92	12.7	15.7	19	19.2
65	2 1/2	60	64	92	108	15.7	19	23.6	28.9
80	3	65	68	108	127	19	22.4	25.9	30.5
100	4	68	75	140	159	22.4	28.4	27.7	33
