Coated Steel Pipe

FBE (Fusion Bond Epoxy) Coated Pipe, Epoxy Coated Carbon Steel Pipe, Single-layer Anti-corrosion Epoxy Powder Pipe, Double Layer FBE Coating Pipes
FBE Coating Pipe

FBE Coating Pipe

Pipe Type: Fbe (Fusion Bond Epoxy) Coated Pipe, Epoxy Coated Carbon Steel Pipe,Single-Layer Anti-Corrosion Epoxy Powder Pipe,Double Layer Fbe Coating Pipes
Specification:Outer Diameter: 20mm~3600mm
Wall Thickness: 1mm~80mm
Length: Random Length, Fixed Length, Srl, Drl
Application: Used For Natural Gas, Petroleum, Water & Sewage, And Pipe Systems
Coating Standard:Din 30670, Din 30671, Din 30678, Sy/T0413-2002 Can/Csa-Z245.21etc.
Pipe Type: Submerged Arc Welded (Lsaw/Ssaw), Electrci Resistance Welded
Surface:One Layer / Double Layer Fbe Anti-Corrosive Coating Powder (200um~800um)
Ends: Plain,Beveled, Thread With Couplings Or Sockets; Plastic Caps And Steel Rings Can Be Provided If Possible
Packing:Waterproof Paper Wrapped, Steel Strips Bundled, Two Tags On Each Bundle

  • FBE Coating Pipe
  • FBE Coating Pipe
  • FBE Coating Pipe
  • FBE Coating Pipe
  • Description
  • Specification
  • Standard
  • Process
  • Packing

Description

pipe type: fbe (fusion bond epoxy) coated pipe, epoxy coated carbon steel pipe,single-layer anti-corrosion epoxy powder pipe,double layer fbe coating pipes
specification:outer diameter: 20mm~3600mm
wall thickness: 1mm~80mm
length:  random length, fixed length, srl, drl
application: used for natural gas, petroleum, water & sewage, and pipe systems
coating standard:din 30670, din 30671, din 30678, sy/t0413-2002 can/csa-z245.21etc.
pipe type: submerged arc welded (lsaw/ssaw), electrci resistance welded
surface:one layer / double layer fbe anti-corrosive coating powder (200um~800um)
ends: plain,beveled, thread with couplings or sockets; plastic caps and steel rings can be provided if possible
packing:waterproof paper wrapped, steel strips bundled, two tags on each bundle


fbe coating steel pipe is fusion bonded epoxy coating steel pipe.it is a kind of external heat resin used for pipes.with a form of dry powder at thickness 400-600 microns on to the heated surface of pipe.once the fbe coated on the pipe surface,the fbe film provides an extremely hard surface with great adhesion to the surface of pipe.the fbe layer in a even form and have good resistance to the chemical reaction.

the steel pipes are treated by shot blasting and intermediate frequency preheating before painting, and then the epoxy powder coating is sprayed on the surface of the heated pipe products by electrostatic spraying method, which is fused and bonded on the surface of the steel pipe and solidified to form a coating. fbe coating is usually one – step film – forming structure.


Specification

epoxy primer coated pipes coating specification

external coating


coating type

coating standard


3lpe/3lpp

din30670-1991,can/csa z245,21-2010,iso21809-1-2009 sy/t 0413-2002,gb/t23257-2009


2lpe/2lpp

sy/t 0315-2002,gb/t23257-2009,iso21809-1-2009


fbe(fusion-bond epoxy)

sy/t 0315-2005,awwa c213-2001,can/csaz245.20-2010,iso218909-2-2007,api rp5l9-2001


bitumen coating

enamel &tape hot-applied

bs534-1990,awwa203-2002,awwa214-2000


liquid epoxy coating

awwwa c210-2007


polyurethane insulated coating

sy/t0415-1996,cj/t114-2000.en253-1994


internal coating


liquid epoxy coating

awwac210-2007


fbe

awwac213-2001


cement mortar lining

bs534-1990,awwa c205-2001


bitumen coating

bs534-1990

Standard

epoxy primer coated pipes technique data

technique data

moisture content:

<0.5%

particle size:

larger than 250um<0.2% larger than 150um<3.0%

density:

1.2~1.8g/cm3(owing to the different formula and different colors)

recommened film thinkness :

a. in fbe systems: 300-400 microns (12-16 mils) b. as a primer in 3-layer pe or pp systems: 150-300 microns (6-12 mils)

theoretical coverage:

0.6993 m2/kg per mm (134.6 ft2/lb per mil)

operating temperature range:

"-73ºc (-100ºf) to 110ºc (230ºf)

storage time:

12 months if stored below 27ºc (80ºf) and 65% relative humidity.

on sieve:

150μm powder on sieve ≤3%,250μm powder on sieve ≤0.2%

gel time:

under 200℃≥12s, and in accordance with manufacturer’s value ±20%

thermal properties

δh≥45j/g,tg2≥95℃

Process

Packing

bundled package

on bundle of steel tube shall be the same in batch number, steel grade and specification. the rest of tubing less than one bundle should be tied into small bundles.
the weight of each bundle should be less than 50kg. the max weight cannot exceed 80kg of the bundle lf there are special reguirements.
when the length of the steel tube is greater than or equal to 6m, with at least 8 strapping bands for each bundle, divided into 3 groupsand 3-2-3.
when the length of the steel tube is less than 6m, and each bundle is tied at least 5 knots and divided into 3 groups, which are 2-1-2.
when the lenath of the tube is areater than or eowal to 3m, and each bundle is tied with at least 3 bands, divided into 3 aroups. 1-1-1.

showed below


wooden box package

the wooden box is suitable for cold roling or cold drawing seamless steel tube, polished hot rolled stainless steel tube.
when the outer diameter of steel pipe is greater than or equal 10mm, the maximum weight of the container should be 50kg.
when the outer diameter of steel pipe is less than or equal 10mm, the maximum weight of the container should be 30kg.

Specification

epoxy primer coated pipes coating specification

external coating


coating type

coating standard


3lpe/3lpp

din30670-1991,can/csa z245,21-2010,iso21809-1-2009 sy/t 0413-2002,gb/t23257-2009


2lpe/2lpp

sy/t 0315-2002,gb/t23257-2009,iso21809-1-2009


fbe(fusion-bond epoxy)

sy/t 0315-2005,awwa c213-2001,can/csaz245.20-2010,iso218909-2-2007,api rp5l9-2001


bitumen coating

enamel &tape hot-applied

bs534-1990,awwa203-2002,awwa214-2000


liquid epoxy coating

awwwa c210-2007


polyurethane insulated coating

sy/t0415-1996,cj/t114-2000.en253-1994


internal coating


liquid epoxy coating

awwac210-2007


fbe

awwac213-2001


cement mortar lining

bs534-1990,awwa c205-2001


bitumen coating

bs534-1990

Standard

epoxy primer coated pipes technique data

technique data

moisture content:

<0.5%

particle size:

larger than 250um<0.2% larger than 150um<3.0%

density:

1.2~1.8g/cm3(owing to the different formula and different colors)

recommened film thinkness :

a. in fbe systems: 300-400 microns (12-16 mils) b. as a primer in 3-layer pe or pp systems: 150-300 microns (6-12 mils)

theoretical coverage:

0.6993 m2/kg per mm (134.6 ft2/lb per mil)

operating temperature range:

"-73ºc (-100ºf) to 110ºc (230ºf)

storage time:

12 months if stored below 27ºc (80ºf) and 65% relative humidity.

on sieve:

150μm powder on sieve ≤3%,250μm powder on sieve ≤0.2%

gel time:

under 200℃≥12s, and in accordance with manufacturer’s value ±20%

thermal properties

δh≥45j/g,tg2≥95℃

Process

Packing

bundled package

on bundle of steel tube shall be the same in batch number, steel grade and specification. the rest of tubing less than one bundle should be tied into small bundles.
the weight of each bundle should be less than 50kg. the max weight cannot exceed 80kg of the bundle lf there are special reguirements.
when the length of the steel tube is greater than or equal to 6m, with at least 8 strapping bands for each bundle, divided into 3 groupsand 3-2-3.
when the length of the steel tube is less than 6m, and each bundle is tied at least 5 knots and divided into 3 groups, which are 2-1-2.
when the lenath of the tube is areater than or eowal to 3m, and each bundle is tied with at least 3 bands, divided into 3 aroups. 1-1-1.

showed below


wooden box package

the wooden box is suitable for cold roling or cold drawing seamless steel tube, polished hot rolled stainless steel tube.
when the outer diameter of steel pipe is greater than or equal 10mm, the maximum weight of the container should be 50kg.
when the outer diameter of steel pipe is less than or equal 10mm, the maximum weight of the container should be 30kg.

If you have any inquiries and questions, please contact us at any time. Thanks in advance. Welcome!
